if (UseBiasedLocking) {
result->set_mark(ik->prototype_header());
} else {
result->set_mark(markOopDesc::prototype());
}
result->set_klass_gap(0);
result->set_klass(k_entry);
7.把对象地址引入栈,并继续执行下一个字节码
SET_STACK_OBJECT(result, 0);
UPDATE_PC_AND_TOS_AND_CONTINUE(3, 1);
8.若该类型没有被解析,就会调用InterpreterRuntime的_new函数完成慢速分配
// Slow case allocation
CALL_VM(InterpreterRuntime::_new(THREAD, METHOD->constants(), index),
handle_exception);
SET_STACK_OBJECT(THREAD->vm_result(), 0);
THREAD->set_vm_result(NULL);
UPDATE_PC_AND_TOS_AND_CONTINUE(3, 1);
以上就是快速分配的过程,其流程图如下,关键在于快速分配在Eden区所使用的无锁指针碰撞技术
二、慢速分配
接下来看看慢速分配是如何进行的:
1.InterpreterRuntime的_new函数定义在/hotspot/src/share/vm/interpreter/interpreterRuntime.cpp中:
IRT_ENTRY(void, InterpreterRuntime::_new(JavaThread* thread, constantPoolOopDesc* pool, int index))
klassOop k_oop = pool->klass_at(index, CHECK);
instanceKlassHandle klass (THREAD, k_oop);
// Make sure we are not instantiating an abstract klass
klass->check_valid_for_instantiation(true, CHECK);
// Make sure klass is initialized
klass->initialize(CHECK);
oop obj = klass->allocate_instance(CHECK);
thread->set_vm_result(obj);
IRT_END
该函数在进行了对象类的检查(确保不是抽象类)和对该类型进行初始化后,调用instanceKlassHandle的allocate_instance进行内存分配。
其中instanceKlassHandle类由DEF_KLASS_HANDLE宏进行声明,注意该类重载了成员访问运算符”->”,这里的一系列成员方法的访问实际上是instanceKlass对象的访问。
type* operator -> () const { return (type*)obj()->klass_part(); }
2.所以实际上是调用了instanceKlass的allocate_instance()成员函数:
allocate_instance()定义在/hotspot/src/share/vm/oops/instanceKlass.cpp
(1).检查是否设置了Finalizer函数,获取对象所需空间的大小
instanceOop instanceKlass::allocate_instance(TRAPS) {
bool has_finalizer_flag = has_finalizer(); // Query before possible GC
int size = size_helper(); // Query before forming handle.
(2).调用CollectedHeap的obj_allocate()创建一个instanceOop(堆上的对象实例),并根据情况注册Finalizer函数
KlassHandle h_k(THREAD, as_klassOop());
instanceOop i;
i = (instanceOop)CollectedHeap::obj_allocate(h_k, size, CHECK_NULL);
if (has_finalizer_flag && !RegisterFinalizersAtInit) {
i = register_finalizer(i, CHECK_NULL);
}
return i;
3.CollectedHeap::ojb_allocate()定义在/hotspot/src/share/vm/gc_interface/CollectedHeap.hpp中,它将转而调用内联函数obj_allocate()
4.obj_allocate()定义在/hotspot/src/share/vm/gc_interface/CollectedHeap.inline.h中,若当正处于gc状态时,不允许进行内存分配申请,否则将调用common_mem_allocate_init()进行内存分配并返回获得内存的起始地址,随后将调用post_allocation_setup_obj()进行一些初始化工作
oop CollectedHeap::obj_allocate(KlassHandle klass, int size, TRAPS) {
//...assert
HeapWord* obj = common_mem_allocate_init(size, false, CHECK_NULL);
post_allocation_setup_obj(klass, obj, size);
NOT_PRODUCT(Universe::heap()->check_for_bad_heap_word_value(obj, size));
return (oop)obj;
}
5.common_mem_allocate_init()分为两部分,将分别调用common_mem_allocate_noinit()进行内存空间的分配和调用init_obj()进行对象空间的初始化
