线上服务器，安装CentOS 7.2 x64最小化安装，需要做链路聚合，双网卡绑定。在CentOS 6.x 和 CentOS 7上测试都OK，于是直接开搞。
说明下，以下环境是在虚拟机中实现的：
系统： CentOS 7.2 x64 最小化安装。
为了方便演示，这里共有三张网卡：
eno16777736 ： 桥接网卡：10.0.0.11/24
剩下的两张网卡准备做绑定：
eno33554984
eno50332208
[root@linuxidc ~]# nmcli con sh NAME UUID TYPE DEVICE Wired connection 2 bf0cf9b6-c7fb-4c0a-ada4-abfb650dd5f0 802-3-ethernet -- Wired connection 1 5b4e0b3e-c469-404c-8839-76d18442fc20 802-3-ethernet -- eno16777736 100e462e-c0d0-4271-9b5a-1c8e47ff0d03 802-3-ethernet eno16777736 [root@linuxidc ~]# nmcli con del 5b4e0b3e-c469-404c-8839-76d18442fc20 bf0cf9b6-c7fb-4c0a-ada4-abfb650dd5f0 Connection 'Wired connection 1' (5b4e0b3e-c469-404c-8839-76d18442fc20) successfully deleted. Connection 'Wired connection 2' (bf0cf9b6-c7fb-4c0a-ada4-abfb650dd5f0) successfully deleted. [root@linuxidc ~]# nmcli con add type team ifname team0 con-name team0 config '{"runner":{"name":"roundrobin"}}' Connection 'team0' (913f05c2-15d8-49a9-a35f-8bc5ee843c0c) successfully added. [root@linuxidc ~]# nmcli con add type team-slave ifname eno50332208 con-name team0-port2 master team0 Connection 'team0-port2' (1583854c-1f85-4c76-8cc7-c643071d4b82) successfully added. [root@linuxidc ~]# nmcli con mod team0 ipv4.address "192.168.121.100/24" [root@linuxidc ~]# nmcli con mod team0 ipv4.method manual [root@linuxidc ~]# nmcli con sh NAME UUID TYPE DEVICE eno16777736 100e462e-c0d0-4271-9b5a-1c8e47ff0d03 802-3-ethernet eno16777736 team0-port2 1583854c-1f85-4c76-8cc7-c643071d4b82 802-3-ethernet -- team0-port1 bfd408b4-76d9-4f5c-ad5b-4d92430eb6ba 802-3-ethernet -- team0 913f05c2-15d8-49a9-a35f-8bc5ee843c0c team --
到这里都没毛病。
[root@linuxidc ~]# nmcli con up team0 Error: Connection activation failed: NetworkManager plugin for 'team' unavailable
什么鬼？NetworkManager "team"插件不可用。于是开始排查。
是否存在team模块
[root@linuxidc ~]# lsmod | egrep *team*
木有。那直接restart network好了。
[root@linuxidc ~]# systemctl restart network Job for network.service failed because the control process exited with error code. See "systemctl status network.service" and "journalctl -xe" for details. [root@linuxidc ~]# systemctl status network ... Mar 25 04:47:56 linuxidc network[2742]: Bringing up interface team0: Error: Connection activation failed: NetworkManager plugin for 'team' unavailable Mar 25 04:47:56 linuxidc network[2742]: [FAILED] ...
一样的报错，难道什么包没有安装到？
[root@linuxidc ~]# yum list all | grep NetworkManager* NetworkManager.x86_64 1:1.0.6-27.el7 @anaconda NetworkManager-libnm.x86_64 1:1.0.6-27.el7 @anaconda NetworkManager-tui.x86_64 1:1.0.6-27.el7 @anaconda NetworkManager-wifi.x86_64 1:1.0.6-27.el7 @anaconda NetworkManager-adsl.x86_64 1:1.0.6-27.el7 yum NetworkManager-bluetooth.x86_64 1:1.0.6-27.el7 yum NetworkManager-glib.x86_64 1:1.0.6-27.el7 yum NetworkManager-libreswan.x86_64 1.0.6-3.el7 yum NetworkManager-libreswan-gnome.x86_64 1.0.6-3.el7 yum NetworkManager-team.x86_64 1:1.0.6-27.el7 yum NetworkManager-wwan.x86_64 1:1.0.6-27.el7 yum
哎哟，还真有个NetworkManager-team没有安装叻。
[root@linuxidc ~]# yum install NetworkManager-team -y
然后再次尝试：
