Nmap亦称为Network Mapper(网络映射)是一个开源并且通用的用于Linux系统/网络管理员的工具。nmap用于探查网络、执行安全扫描、网络核查并且在远程机器上找出开放端口。它可以扫描在线的主机、操作系统、包过滤器和远程主机上的开放端口。
Nmap 命令和示例
我会分两个章节讲述NMAP的常见的使用方法，这篇是nmap系列的第一部分(译注:原文为I’ll be covering most of NMAP usage in two different parts and this is the first part of nmap serious,这里serious可能为笔误，应该为series)。在这个步骤里，我用两个没有防火墙的服务器来测试nmap命令的工作。
192.168.0.100 – server1.tecmint.com
192.168.0.101 – server2.tecmint.com
Nmap 命令使用 # nmap [Scan Type(s)] [Options] {target specification} 如何在Linux上安装nmap如今大部分Linux发行版像Red Hat, CentOS, Fedoro, Debian 和 Ubuntu已经在它们默认的包管理仓库中包含了nmap，可以通过Yum 和 APT安装、管理和更新软件包。在这些发行版上安装nmap，可以使用下面的命令。
# yum install nmap [基于 Red Hat 的发行版] $ sudo apt-get install nmap [基于 Debian 的发行版]安装了最新的nmap程序之后，你就可以跟着这篇文章中的示例指令来学习了。
1. 带主机名和IP地址扫描系统nmap工具提供了不同的方法来扫描一个系统。在这个例子中，我使用主机名为server2.tecmint.com的机器执行扫描来找出所有开放端口，服务和系统上的MAC地址。
使用主机名扫描 [root@server1 ~]# nmap server2.tecmint.com Starting Nmap 4.11 ( ) at 2013-11-11 15:42 EST Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 957/tcp open unknown 3306/tcp open MySQL 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 1 IP address (1 host up) scanned in 0.415 seconds You have new mail in /var/spool/mail/root 使用IP地址扫描 [root@server1 ~]# nmap 192.168.0.101 Starting Nmap 4.11 ( ) at 2013-11-18 11:04 EST Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 958/tcp open unknown 3306/tcp open mysql 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 1 IP address (1 host up) scanned in 0.465 seconds You have new mail in /var/spool/mail/root 2. 使用"-v"选项扫描你可以看到带"-v"选项的命令给出了关于远程机器的更多信息。
[root@server1 ~]# nmap -v server2.tecmint.com Starting Nmap 4.11 ( ) at 2013-11-11 15:43 EST Initiating ARP Ping Scan against 192.168.0.101 [1 port] at 15:43 The ARP Ping Scan took 0.01s to scan 1 total hosts. Initiating SYN Stealth Scan against server2.tecmint.com (192.168.0.101) [1680 ports] at 15:43 Discovered open port 22/tcp on 192.168.0.101 Discovered open port 80/tcp on 192.168.0.101 Discovered open port 8888/tcp on 192.168.0.101 Discovered open port 111/tcp on 192.168.0.101 Discovered open port 3306/tcp on 192.168.0.101 Discovered open port 957/tcp on 192.168.0.101 The SYN Stealth Scan took 0.30s to scan 1680 total ports. Host server2.tecmint.com (192.168.0.101) appears to be up ... good. Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 957/tcp open unknown 3306/tcp open mysql 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 1 IP address (1 host up) scanned in 0.485 seconds Raw packets sent: 1681 (73.962KB) | Rcvd: 1681 (77.322KB) 扫描多台主机你可以简单地通过在namap后写上它们的IP地址或者主机名来扫描多台主机。
[root@server1 ~]# nmap 192.168.0.101 192.168.0.102 192.168.0.103 Starting Nmap 4.11 ( ) at 2013-11-11 16:06 EST Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 957/tcp open unknown 3306/tcp open mysql 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 3 IP addresses (1 host up) scanned in 0.580 seconds 4. 扫描整个子网你可以通过通配符来使nmap扫描整个子网或者IP段。
[root@server1 ~]# nmap 192.168.0.* Starting Nmap 4.11 ( ) at 2013-11-11 16:11 EST Interesting ports on server1.tecmint.com (192.168.0.100): Not shown: 1677 closed ports PORT STATE SERVICE 22/tcp open ssh 111/tcp open rpcbind 851/tcp open unknown Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 957/tcp open unknown 3306/tcp open mysql 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 256 IP addresses (2 hosts up) scanned in 5.550 seconds You have new mail in /var/spool/mail/root从上面的输出你可以看到nmap扫描了整个子网，并给出了网络中在线主机的信息。
5. 使用IP地址的最后一段扫描多台主机你可以简单地通过指定IP地址的最后8位执行扫描多台主机。比如说，这里我在IP地址为192.168.0.101, 192.168.0.102 and 192.168.0.103的机器上执行了扫描。
[root@server1 ~]# nmap 192.168.0.101,102,103 Starting Nmap 4.11 ( ) at 2013-11-11 16:09 EST Interesting ports on server2.tecmint.com (192.168.0.101): Not shown: 1674 closed ports PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 111/tcp open rpcbind 957/tcp open unknown 3306/tcp open mysql 8888/tcp open sun-answerbook MAC Address: 08:00:27:D9:8E:D7 (Cadmus Computer Systems) Nmap finished: 3 IP addresses (1 host up) scanned in 0.552 seconds You have new mail in /var/spool/mail/root相关阅读：
