Flink具有Table API和SQL-用于统一流和批处理。
Table API是用于Scala和Java的语言集成查询API，它允许以非常直观的方式组合来自关系运算符（例如选择，过滤和联接）的查询。
Flink的SQL支持基于实现SQL标准的Apache Calcite。无论输入是批处理输入（DataSet）还是流输入（DataStream），在两个接口中指定的查询都具有相同的语义并指定相同的结果。
Table API和SQL尚未完成所有功能，正在积极开发中，支持程度需查看
多表连接案例
pom依赖flink 版本为:1.9.3
<dependencies> <!-- Apache Flink dependencies --> <!-- These dependencies are provided, because they should not be packaged into the JAR file. --> <dependency> <groupId>org.apache.flink</groupId> <artifactId>flink-java</artifactId> <version>${flink.version}</version> <scope>provided</scope> </dependency> <dependency> <groupId>org.apache.flink</groupId> <artifactId>flink-streaming-java_${scala.binary.version}</artifactId> <version>${flink.version}</version> </dependency> <dependency> <groupId>org.apache.flink</groupId> <artifactId>flink-table-api-java-bridge_2.11</artifactId> <version>${flink.version}</version> </dependency> <dependency> <groupId>org.apache.flink</groupId> <artifactId>flink-table-planner-blink_2.11</artifactId> <version>${flink.version}</version> </dependency> <dependency> <groupId>org.apache.flink</groupId> <artifactId>flink-table-api-java</artifactId> <version>${flink.version}</version> </dependency> 模拟一个实时流 import lombok.Data; @Data public class Product { public Integer id; public String seasonType; }自定义Source
import common.Product; import org.apache.flink.streaming.api.functions.source.SourceFunction; import java.util.ArrayList; import java.util.Random; public class ProductStremingSource implements SourceFunction<Product> { private boolean isRunning = true; @Override public void run(SourceContext<Product> ctx) throws Exception { while (isRunning){ // 每一秒钟产生一条数据 Product product = generateProduct(); ctx.collect(product); Thread.sleep(1000); } } private Product generateProduct(){ int i = new Random().nextInt(100); ArrayList<String> list = new ArrayList(); list.add("spring"); list.add("summer"); list.add("autumn"); list.add("winter"); Product product = new Product(); product.setSeasonType(list.get(new Random().nextInt(4))); product.setId(i); return product; } @Override public void cancel() { } } 主程序 public class TableStremingDemo { public static void main(String[] args) throws Exception { StreamExecutionEnvironment bsEnv = StreamExecutionEnvironment.getExecutionEnvironment(); // 使用Blink EnvironmentSettings bsSettings = EnvironmentSettings.newInstance().useBlinkPlanner().inStreamingMode().build(); StreamTableEnvironment bsTableEnv = StreamTableEnvironment.create(bsEnv, bsSettings); SingleOutputStreamOperator<Item> source = bsEnv.addSource(new MyStremingSource()) .map(new MapFunction<Item, Item>() { @Override public Item map(Item value) throws Exception { return value; } }); // 分割流 final OutputTag<Item> even = new OutputTag<Item>("even") { }; final OutputTag<Item> old = new OutputTag<Item>("old") { }; SingleOutputStreamOperator<Item> sideOutputData = source.process(new ProcessFunction<Item, Item>() { @Override public void processElement(Item value, Context ctx, Collector<Item> out) throws Exception { if (value.getId() % 2 == 0) { ctx.output(even,value); }else{ ctx.output(old,value); } } }); DataStream<Item> evenStream = sideOutputData.getSideOutput(even); DataStream<Item> oldStream = sideOutputData.getSideOutput(old); // 注册两个 表 : evenTable,oddTable bsTableEnv.registerDataStream("evenTable",evenStream , "name,id"); bsTableEnv.registerDataStream("oddTable", oldStream, "name,id"); // 执行sql 输出Table Table queryTable = bsTableEnv.sqlQuery("select a.id,a.name,b.id,b.name from evenTable as a join oddTable as b on a.name = b.name"); queryTable.printSchema();; // 获取流 DataStream<Tuple2<Boolean, Tuple4<Integer, String, Integer, String>>> dataStream = bsTableEnv.toRetractStream(queryTable, TypeInformation.of(new TypeHint<Tuple4<Integer,String,Integer,String>>(){})); dataStream.print(); bsEnv.execute("demo"); } } 结果打印
